Compact and Portable
Semiconductors are pretty compact and that makes it ever so flexible and portable to carry around. The physical size and aspect of these devices are as small as that of electron tubes which is pretty small. This is why it can be used in various circuit boards, chips, transistors, and more with ease. A lot of our electrical devices have become smaller in size whilst improving in performance and semiconductors are one key reason for that.
Can operate on low-voltage
Another great thing about semiconductor devices is that they can run easily even on low voltages without affecting the efficiency of the performance. They require minimal voltage to operate and consume very little power as compared to other major electrical components. This allows them to be integrated into the devices without much need for a heavy-duty power supply.
No requirement for warm-time
Semiconductor doesn’t require warm-up time to start the operation like many other electrical components. It doesn’t need to be pre-heated to a certain temperature to allow the functioning which is why it can start operating as soon as the circuit is switched on. This is a welcome change from the previous era where electrical components needed to be booted up and left aside for a period before allowing the operation to commence.
Longevity
Semiconductor devices have a very large operation lifespan and can run for unlimited time until there are some malfunctions in the voltage supply or circuits which erodes or burns it. The usage cycle of semiconductors has given manufacturers a great viable option instead of previous electron tubes which came with a limited lifespan. This helps in manufacturing machines with a larger life span.
Ability to withstand mechanical shocks
Devices with electron tubes often had a hard time withstanding mechanical shocks as any falling or breaking of the device would result in damage to the tube and need replacement. This used to affect lot many electronic devices in the past. Semiconductors meanwhile can withstand mechanical shocks to a large extent and don’t cause damage to the device’s falling or breaking.
No vacuum deterioration
On normal electron tubes, the transistors need to have a vacuum created for it to function. This causes vacuum deterioration and performance issues a lot of the time. With semiconductors, there is no need for vacuum creation in the transistors, this saves on the vacuum deterioration and on the performance loss allowing it to function seamlessly.
N-type semiconductors
N-type semiconductors are the result of adding a dopant that has five valence electrons, such as phosphorus. Because the silicon atoms all have four valence electrons, the phosphorus will form a covalent bond with each one. However, that leaves one electron in each phosphorus atom out of the bonded grid. The result is that those electrons can flow freely throughout the circuit, generating electricity when voltage is applied. When a negative voltage is applied, it forces the unbonded electrons through the circuit.
P-type semiconductors
P-type semiconductors work by a similar concept as N-type semiconductors, except dopants used to make a P-type semiconductor only have three valence electrons. These dopants, such as Boron, bind to three of the four valence electrons in the silicon crystal. However, this leaves a “hole” behind that is positively charged. Electrons, which are negatively charged, are attracted to the hole; as they move, they leave another hole behind, which is dutifully filled by another electron. When a negative voltage is applied, the electrons are forced away from it and toward the positively charged hole. As these electrons move through the holes left behind by the missing covalent bond, electricity is generated.
List of Semiconductor Materials
Germanium (Ge)
The semiconductor material like germanium is from group IV in the periodic table. This material was used in early devices which range from diodes to early transistors. Diodes show a temperature coefficient & higher reverse conductivity so that early transistors could experience thermal runaway. It provides superior charge carrier mobility as compared to silicon, so used in some RF-based devices.
Silicon (S)
Silicon material is a group IV element in the periodic table of chemical elements and it is the most frequently used semiconductor material. These materials are very simple to fabricate and offer the best mechanical & electrical properties. When these materials are used in ICs, then it forms good quality silicon dioxide for insulation layers In between various active elements of the chip.
Gallium Arsenide (GaAs)
After Si, the Gallium arsenide semiconductor is the most widely used material and it is III-V group element in the periodic table. It is broadly used in high-performance-based RF devices where the high electron mobility of this element is used. In other III-V semiconductors, it is also used as substrate-like GaInNAs & InGaAs. This material has less hole mobility as compared to Silicon. It is also quite complex to fabricate & also increases the GaAs devices cost.
Silicon Carbide (SiC)
Silicon carbide material is an IV group element in the periodic table. These elements are used in power devices wherever their losses are considerably less & high operating temperatures as compared to Si-based devices. This material has a breakdown capacity as compared to silicon which is above ten times. The silicon carbide material forms are used in blue and yellow color LEDs.
Gallium Nitride (GaN)
Gallium Nitride or GaN material is an III-V group element in the periodic table. It is most widely used in microwave transistors wherever maximum powers & temperatures are required and also used in microwave ICs. This semiconductor material is hard to dope to provide p-type regions & also responsive to electrostatic discharge however quite not sensitive to ionizing radiation. This material has been used in blue color LEDs.
Gallium Phosphide (GaP)
Gallium Phosphide or GaP semiconductor material is an III-V group element in the periodic table. This material is used in early low brightness to medium based LEDs which generate different colors based on the addition of dopants. Pure GaP generates green light, nitrogen-doped emits yellow-green and ZnO doped emits red color.
Dmium Sulphide (CdS)
Cadmium Sulphide or CdS semiconductor material is an II-VI group element in the periodic table. This material is used in solar cells & photoresistors.
Lead Sulphide (PbS)
Lead Sulphide or PbS semiconductor material is an IV-VI group element in the periodic table, used in early radio detectors called as Cat’s Whiskers’ wherever a tip contact was designed by using thin wire on the galena to give signals rectification.
Computing
Microchips and computers are usually the first connection people make. Depending on the type of chip, a semiconductor uses binary code to direct the commands you give it, whether it’s to launch a program or download and save a document. Microprocessors, memory, and graphic processing units (GPUs) are common semiconductors for computers.
Telecommunication
The principle of semiconductors for telecommunication is the same: to control machine functions. The difference is the types of chips used and what they're used for. At the same time, their design differs from device to device. A smartphone’s semiconductor chips affect its display, navigation, battery use, 4G reception, and more.
Household Appliances
Fridges, microwaves, washing machines, air conditioners, and other machines around the home and office operate thanks to semiconductors. Different chips control temperatures, timers, automated features, and so on. Our spaces are already full of appliances to make everyday habits easier, while smart technology and the Internet of Things (IoT) add to them.
Banking
Once you understand what semiconductors can do, it’s easier to imagine how different parts of our high-tech world benefit from them. Banks are major investors, especially in the best microchips manufacturers have to offer. Computers and their banking systems for online communication, digital accounting, cloud platforms, and more are key.
Security
When it comes to security, semiconductors have both improved and hindered it. The evolution of microchips alongside many other parts of digital technology has opened the way to new and intelligent threats. However, these same innovations also help defend against them. A semiconductor chip’s contribution to cybersecurity starts from the hardware.
Healthcare
The medical field uses advanced technology. Complex and risky surgeries are safer with the help of machines, operating with precision. Monitors and pacemakers are popular too. Even talking to patients and diagnosing symptoms is possible through video conferencing alone.
Transportation
Cars, buses, trains, and planes are just much bigger devices that also use semiconductors. If you value GPS, free Wi-Fi, or the polite voice alerting you about each stop, then you can appreciate how these tiny but wonderful chips enhance everyday habits.
Manufacturing
The benefits of semiconductors come full circle to improve their own manufacturing and that of every other commercial product. Machines in factories do specific and repetitive work, the result of carefully set up hardware and software.
Semiconductors work by enabling the valence electrons, those located in the outer shell of an atom, to bind with the valence electrons of other atoms. Most semiconductors can bind with four valence electrons at once, effectively creating a bound mesh of silicon molecules, tied together by a network of valence electrons.
But in order to conduct electricity, the valence electrons have to flow throughout the circuit. Locked in a grid-like this means that pure silicon crystals are ineffective for electrical applications. In order to make them useful, impurities (or other elements) are introduced to the silicon crystal. These impurities are what enable the electricity to ultimately flow across a semiconductor.
In order to break the electron gridlock, semiconductors need to undergo a process called doping. Doping is the process of inserting impurities into the silicon crystal (or other element being used as a semiconductor). Exactly which type of dopant is used can create a different type of semiconductor, each of which enables the flow of electricity throughout a circuit.
The properties of semiconductors are inseparable from insulators and conductors. The nature of these two electricity does not change easily from the influence of temperature, light, temperature to magnetism. This makes semiconductors very sensitive. Semiconductors have a resistance between 10-6 – 104 Ωm. The following are the properties of semiconductors including:
Negative Temperature Coefficient
Semiconductors have negative properties. This is in contrast to metals which have a positive temperature coefficient of resistance.
High Thermoelectric Power:
Semiconductors are capable of providing high thermoelectric power. Because the nature of the semiconductor is in the middle so that it has a positive or negative sign on the metal it relates to.
Rectification
Semiconductors have a rectification relationship so that the components in the semiconductor will not conflict with each other.
Energy Gap: Semiconductors have a band gap, an energy range positioned between the valence band (with tightly bound electrons) and the conduction band (permitting electron movement), influencing their conductive or insulating nature.
Dopant Introduction: Controlled introduction of impurities (doping) into semiconductors intentionally alters their electrical characteristics, generating excess charge carriers (N-type) or “holes” (P-type) for conductivity control.
Temperature Responsiveness: Semiconductors’ conductivity varies with temperature, making them suitable for applications like thermistors and temperature sensors.
Light Sensitivity: Certain semiconductors become more conductive upon light exposure, proving valuable in photodetectors and solar cells.
Mechanical Influence: Semiconductors’ resistance can change with mechanical stress (piezo-resistivity), applied in strain gauges and pressure sensors.
Heat Conductance: With intermediate thermal conductivity, semiconductors manage controlled heat dissipation, crucial for integrated circuits.
Dielectric Qualities: Semiconductors can act as insulating dielectrics under specific circumstances, contributing to capacitors and energy storage mechanisms.
Electroluminescence: When subjected to voltage, specific semiconductors emit light, essential in LEDs and displays.
Quantum Aspects: On the nanoscale, semiconductors reveal quantum effects exploited in quantum dots and quantum well structures for advanced uses.
Hall Effect: Semiconductors exhibit the Hall effect, where an electric field perpendicular to the current generates measurable voltage, applicable in Hall sensors and current measurement.
Carrier Mobility: The movement ability of charge carriers (electrons and holes) within semiconductors is determined by carrier mobility, influencing device efficiency and speed.
Resistivity (ρ): The resistivity decreases with the increase of temperature because of the increase in number of the mobile charge carriers and thus making the temperature coefficient negative.
Conductivity (σ): The semiconductors act as insulators as zero kelvin but when the temperature increases they start working as the conductors.
Carrier Concentration (n or p): In semiconductors, the carrier concentration refers to the number of charge carriers (electrons or holes) per unit volume.
Wafer manufacturing
The first step in semiconductor manufacturing is to create a wafer, which is a thin slice of semiconductor material, typically silicon. The wafer is made by slicing a large ingot of silicon into thin slices. The ingot is created by melting silicon and then slowly cooling it. The wafers are then polished to create a smooth surface. The wafer manufacturing process is a complex and demanding process. The wafers must be very thin and very smooth, with no defects. Any defects can cause the semiconductor to malfunction. The process begins with the creation of a silicon ingot.
Oxidation
The next step is to grow a thin layer of silicon dioxide on the surface of the wafer. This layer is used to protect the underlying silicon from damage and to provide a surface for the next steps of the process. The silicon dioxide is grown by exposing the wafer to oxygen at high temperatures. The oxidation process is a chemical reaction that occurs when silicon is exposed to oxygen. The oxygen atoms react with the silicon atoms to form silicon dioxide. The silicon dioxide layer is a very good insulator, which helps to protect the underlying silicon from damage.
Photolithography
In photolithography, a pattern is created on the surface of the wafer using a light-sensitive chemical called a photoresist. The photoresist is then exposed to ultraviolet light, which hardens the areas that are exposed to the light. The unexposed areas are then washed away, leaving behind a pattern of exposed silicon dioxide. The photoresist is used to create a pattern on the surface of the wafer. The pattern is used to define the location of the transistors and other components of the semiconductor.
Etching
The next step is to etch away the exposed silicon dioxide using a chemical or plasma etch. This leaves behind a pattern of exposed silicon, which is used to create the transistors and other components of the semiconductor. The etching process creates the desired patterns in the semiconductor material. The most common type of etching is chemical etching, which uses a chemical to dissolve the material that is not protected by the photoresist.
Deposition
In deposition, a thin layer of material is deposited on the surface of the wafer. This material can be used to create the electrodes of the transistors, the insulation between the transistors, or other components of the semiconductor. The deposition process is used to add material to the semiconductor wafer. The most common type of deposition is chemical vapor deposition (CVD), which uses a chemical reaction to deposit the material on the wafer. This process begins with the creation of a plasma.
Ion implantation
Ion implantation is a process used to introduce impurities into the semiconductor material. This is done by bombarding the wafer with ions of the desired impurity. The impurities can be used to change the electrical properties of the semiconductor, such as its conductivity. The ion implantation process begins with the creation of a plasma. The plasma is a gas that has been ionized. The ionized gas is then used to accelerate the ions of the desired impurity.
Metal wiring
The next step is to connect the different components of the semiconductor. This is done by depositing a thin layer of metal, such as copper, on the surface of the wafer. The metal is then patterned using photolithography and etched to create the desired connections. The metal wiring process is used to connect the different components of the semiconductor. The metal is deposited on the wafer using a process called electroplating. The metal is then patterned using photolithography and etched to create the desired connections.
Electrical die sorting
The final step is to test the electrical properties of the semiconductor. This is done by applying a voltage to the different components and measuring the current that flows. Any semiconductors that do not meet the desired specifications are discarded. The electrical die-sorting process is used to test the electrical properties of the semiconductor. The semiconductor is tested by applying a voltage to the different components and measuring the current that flows. Any semiconductors that do not meet the desired specifications are discarded.
Packaging
Once the semiconductor has been manufactured, it is packaged in a protective case and ready for use. The packaging process protects the semiconductor from damage and helps ensure it will function properly. The most common type of packaging is a plastic case with metal leads. The leads are used to connect the semiconductor to other components. The packaging process is the final step in the semiconductor manufacturing process. The semiconductor is packaged in a protective case to protect it from damage and to ensure that it will function properly.
How Long Does It Take to Fabricate a Semiconductor?
On average, the fabrication process can take anywhere from a few weeks to several months, depending on the specific requirements of the semiconductor device being produced. It's important to note that the semiconductor fabrication process is a complex and highly technical process that requires specialized equipment, facilities, and trained personnel. Due to this, the fabrication of a semiconductor can take anywhere from several weeks to three months. Therefore, it’s important for companies that manufacture semiconductors to take this into consideration, as it can impact production schedules and costs.
Technological advancements have resulted in improvements in the semiconductor manufacturing process and materials used, which has contributed to increased reliability and performance in semiconductors, as well as their overall lifespan.
Semiconductors are made from materials such as silicon, germanium, and gallium arsenide, which have improved in quality and purity, leading to better performance and longer lifetimes. In addition, advancements in fabrication technologies, such as photolithography and deposition techniques, have enabled the production of smaller, more complex, and higher-performance devices.
Moreover, improved design techniques and better quality control during the manufacturing process have also contributed to a longer lifespan of semiconductors. Newer materials, such as wide bandgap semiconductors, have also been developed that are able to withstand higher temperatures and operate at higher voltages, which can result in longer lifetimes.
It's worth noting that while the lifespan of semiconductors has improved, they are still susceptible to degradation and failure over time. The lifespan of a semiconductor can vary widely, with some breaking down after two years, while others last for as long as twenty. However, technological advancements continue to push the limits of performance and reliability, leading to even longer lifetimes for semiconductors in the future.
