- Product Introduction
Product Attributes
|
TYPE |
DESCRIPTION |
|---|---|
|
Category |
Integrated Circuits (ICs) Power Management (PMIC) Gate Drivers |
|
Manufacturer |
Texas Instruments |
|
Series |
- |
|
Part Status |
Active |
|
Driven Configuration |
Low-Side |
|
Channel Type |
Independent |
|
Number of Drivers |
2 |
|
Gate Type |
IGBT, N-Channel MOSFET |
|
Voltage - Supply |
4.5V ~ 18V |
|
Logic Voltage - VIL, VIH |
1V, 2.3V |
|
Current - Peak Output (Source, Sink) |
5A, 5A |
|
Input Type |
Non-Inverting |
|
Rise / Fall Time (Typ) |
7ns, 6ns |
|
Operating Temperature |
-40°C ~ 140°C (TJ) |
|
Mounting Type |
Surface Mount |
|
Package / Case |
8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad |
|
Supplier Device Package |
8-HVSSOP |
|
Base Product Number |
UCC27524 |
General description
The UCC27524 device is a dual-channel, high-speed,low-side, gate-driver device capable of effectivelydriving MOSFET and IGBT power switches. TheUCC27524 adds the ability to handle –5V directlyat the input pins for increased robustness. TheUCC27524 is a dual non-inverting driver. Usinga design that inherently minimizes shoot-throughcurrent, the UCC27524 is capable of deliveringhigh-peak current pulses of up to 5A source and5A sink into capacitive loads along with rail-to-raildrive capability and extremely small propagationdelay typically 17ns. In addition, the drivers featurematched internal propagation delays between the twochannels which are very well suited for applicationsrequiring dual-gate drives with critical timing, such assynchronous rectifiers. This also enables connectingtwo channels in parallel to effectively increase currentdrive capability or driving two switches in parallelwith a single input signal. The input pin thresholdsare based on TTL and CMOS compatible low-voltagelogic, which is fixed and independent of the VDDsupply voltage. Wide hysteresis between the high andlow thresholds offers excellent noise immunity.
