Integrated Circuit For LM293DT
1.Manufacturer Product Number;LM293DT
2.Description;IC COMPARATOR 2 GEN PUR 8SOIC
3.Detailed Description;Comparator General Purpose Open-Collector, Open-Drain, Rail-to-Rail 8-SOIC
- Product Introduction
Description
The LM193, LM293, LM393 and LM393W devices consist of two independent lowvoltage comparators designed specifically to operate from a single supply over awide range of voltages. Operation from split power supplies is also possible.These comparators also have a unique characteristic in that the input common-modevoltage range includes ground even though operated from a single power supplyvoltage.The LM393W offers additional ESD robustness of 2 kV HBM on all pins.
Features
• Wide single-supply voltage range or dual supplies: 2 V to 36 V or ±1 V to ±18 V• Very low supply current (0.45 mA) independent of supply voltage (1 mW/comparator at 5 V)• Low input bias current: 20 nA typ.• Low input offset current: ±3 nA typ.• Low input offset voltage: ±1 mV typ.• Input common-mode voltage range includes ground• Low output saturation voltage: 80 mV typ. (Isink = 4 mA)• Differential input voltage range equal to the supply voltage• TTL, DTL, ECL, MOS, CMOS compatible outputs• Available in DFN8 2x2, MiniSO8, TSSOP8, and SO8 packages• LM393W with internal ESD protection: 2 kV HBM
Product Attributes
|
TYPE |
DESCRIPTION |
|---|---|
|
Category |
Integrated Circuits (ICs) Linear Comparators |
|
Manufacturer |
STMicroelectronics |
|
Series |
- |
|
Part Status |
Active |
|
Type |
General Purpose |
|
Number of Elements |
2 |
|
Output Type |
Open-Collector, Open-Drain, Rail-to-Rail |
|
Voltage - Supply, Single/Dual (±) |
2V ~ 36V, ±1V ~ 18V |
|
Voltage - Input Offset (Max) |
5mV @ 30V |
|
Current - Input Bias (Max) |
0.25µA @ 5V |
|
Current - Output (Typ) |
18mA @ 5V |
|
Current - Quiescent (Max) |
2.5mA |
|
CMRR, PSRR (Typ) |
- |
|
Propagation Delay (Max) |
- |
|
Hysteresis |
- |
|
Operating Temperature |
-40°C ~ 105°C |
|
Package / Case |
8-SOIC (0.154", 3.90mm Width) |
|
Mounting Type |
Surface Mount |
|
Supplier Device Package |
8-SOIC |
|
Base Product Number |
LM293 |
